Min. I-oda:1 Piece/Pieces
Ibhulogi: Ukucisha
Ukukhiqiza: 150K
Indawo Yomsuka: UShen Zhen
Isitifiketi: CE/ROSH/UL/ISO9001
|
|
||||
|
Panel item
|
RS236NET-N15
|
|||
|
Panel type
|
a-Si TFT-LCD
|
|||
|
Display mode
|
IPS,Normally black，transmissive display
|
|||
|
Pixels
|
1920*1080
|
|||
|
brightness
|
1500cd/㎡
|
|||
|
Constrast Ratio
|
1000:1
|
|||
|
Response Time
|
1.5/3.5ms
|
|||
|
View angle
|
85/85/80/80
|
|||
|
View area
|
525.22*297.22mm(H*V)
|
|||
|
Dispaly area
|
521.28*293.22mm(H*V)
|
|||
|
Outline Size
|
544.8*320.5*11.5mm(H*V*D)
|
|||
|
Signal Type
|
LVDS
|
|||
|
Working freqyency
|
60Hz
|
|||
|
Working temperature
|
0- 50ﾟC
|
|||
|
Storage Temperature
|
-20 - +60ﾟC
|
|||
|
Display ratio
|
16:9
|
|||
|
Display color
|
16.7m
|
|||
|
Backlight Voltage
|
5V
|
|||
|
Backlight Power Consumption
|
15.2w
|
|||
|
Surface Treatment
|
Haze 1%,Hard coating(3H)
|
|||
|
Weight
|
2.41kgs
|
|||
