Min. I-oda:1 Piece/Pieces
Ibhulogi: Ukucisha
Ukukhiqiza: 500K
Indawo Yomsuka: Shenzhen
Isitifiketi: CE/ROSH/UL/SIO9001
Imodyuli engu-800 ye-LCD ye-LCD eChina, usayizi we-module 13.3inch, le module, le module ingumbala osebenzayo we-matrix lcd module Ukufaka i-oxide TFT (Thin Film Transistor). Iphasiwedi yephaneli ye-TFT-LCD yombala we-TFT-LCD, umshayeli we-Driver ICS, umjikelezo wokulawula kanye ne-Power Supply Circuit.Resuule 1920 * 1080.
I-800Nits module ye-LCD enokubuyiselwa okuphezulu iqinisekisa ukuthi yonke imininingwane ingethulwa kumbukeli, ukuze imininingwane idluliselwe ngokuphelele, futhi lo mphumela obonakalayo ungenza umbukeli uhlaba umxhwele.
I-13.3 inch High Brightness Logness LCD isetshenziswa kabanzi ezimotweni, ukuboniswa kokulawulwa kwezimboni, amakhadi we-elekthronikhi, ama-porses amasha wokushaja, njll.
Isicelo:
| Size | 13.3inch |
| Panel item | RS133NET-N10 |
| Panel type | a-Si TFT-LCD |
| Display mode | IPS,Normally black，transmissive display |
| Pixels | 1920*1080 |
| brightness | 1000cd/m2 |
| Constrast Ratio | 800：1 |
| Response Time | 25ms |
| View angle | 89/89/89/89 |
| View area | 295.07*166.68mm(H*V) |
| Dispaly area | 293.472*165.078mm(H*V) |
| Outline Size | 309.7*184.1*10.1mm(H*V*D) |
| Signal Type | LVDS,30Pin |
| Working freqyency | 60Hz |
| Working temperature | 0- 70ﾟC |
| Storage Temperature | -25- +65.0ﾟC |
| Display ratio | 16:9 |
| Display color | 16.7m |
| Nominal Input Voltage | 3.3V |
| Surface Treatment | Haze |
| Weight | 0.5kgs |
Amathegi ashisayo: Imodyuli engu-800 NCD LCD eChina, China, efektri, eshibhile, intengo, ukuboniswa kwe-LCD ebheke e-LCD, i-49 inch i-waterroof LCD, ukuboniswa kwe-inch ye-inch, ama-inch TV Isikrini se-LCD Screen
Isikrini esingu-24 inch High Bright LCD
Imodyuli engu-1000 ye-LCD ye-LCD ene-Driver Board
