10.3 "LG LA103WF4-SL03 TFT LCD module

Min. I-oda:1 Piece/Pieces

Izimfanelo Zomkhiqizo
Ukupakisha nokulethwa
Other information

Izimfanelo Zomkhiqizo

I-Model No.: LA103WF4-SL03

Ukupakisha nokulethwa

Ukuthengisa Amayunithi:

Piece/Pieces

Isingeniso Somkhiqizo

10.3 I-Inch LG isibonisi LA103WF4-SL03 Ukukhanya Okuphezulu 900nits TFT LCD PENCLight I-Sunlight ibonakale.

Isikrini sangaphandle se-LCD ngokuvamile sisetshenziswa kuma-billboard angaphandle, izinqwaba zokushaja kwangaphandle kanye namabhasi we-elekthronikhi nezinye izindawo. Isikrini esiphakeme se-LCD ukukhulisa ukubonakala kwesikrini se-LCD ngaphansi kokukhanya okuqinile ngokushintsha ukukhanya kwesibani. Inezici ezilandelayo:

1. Ukukhanya okuphezulu

Isikrini esigqamile ukugqama kokuqala okuphezulu, amapharamitha ngokuvamile angaphezu kuka-700cd / M², abonakalayo ngokukhanya okuqinile

2, umehluko omkhulu

Isidingo Sokuxabana Isikrini Esigqamile futhi siphakeme kakhulu, ngokuvamile ngaphezulu kwe-1000: 1, nezinye izindawo ezikhethekile zingafinyelela ku-10000: 1

3, ukusebenza okuhle okuhle

Isikrini esiphakeme se-LCD singasekela ama-7 * amahora angama-24 aqhubekayo umsebenzi ongaphazamiseki, isikrini esivamile se-LCD asikwazi ukwenza umsebenzi oqhubekayo nobusuku

4, impilo yenkonzo ende

Okuhlobene nesikrini se-General LCD, impilo yensiza ye-Outdoor Highlight Screen ikude

brand	LG Display (LG Display)	Model name	LA103WF4-SL03
size	10.3"	Screen type	a-Si TFT-LCD,LCD module
resolution	1920(RGB)×720, 200PPI	Pixel configuration	RGB vertical bar
Display size	243.648(W)×91.368(H) mm	Surface treatment	Anti-fingerprint (AF), Hard coating (3H), anti-reflection treatment
Brightness(cd/m²)	900 cd/m² (Typ.)	contrast	1100:1 (Typ.)
Viewing Angle	89/89/89/89 (Min.)(CR≥10)	Apply to	Outdoor highlight, car display
Signal system	LVDS (2 ch, 8-bit) , 60 pins , terminal	Appearance of size	262.28×113.19×13.09(H×V×D) mm
Maximum rated	Storage temperature: -40 ~ 95 °C Working temperature: -30 ~ 85 °C Vibration resistance: 3.0g (29.4m /s²)

Amathegi ashisayo: 10.3 "LG LA103WF4-SL03 TFT LCD module, China, Factory, Isikrini se-LCD, isikrini esiphakeme se-LCD, isikrini esiphakeme se-LCD, i-Outdoor LCD 86 inch, Iphaneli engu-15 4 inch TFT Panel, isikrini se-10 1 inch IPS , i-LCD Panel, i-LCD module, isibonisi esiphakeme kakhulu.
