Min. I-oda:1 Piece/Pieces
I-Model No.: EV101WXM-N81
I-EV101WXM-N81 iyimodyuli engu-10.1-inch LCD usebenzisa ubuchwepheshe be-A-SI TFT-LCD. Ifakwe i-wacklight ye-wackled, kufaka phakathi i-LED Driver Driver Drayivu, akunakuthinta. Isixazululo Sokubonisa singu-1280 (RGB) × 800 (WXGA), isilinganiso se-Aspect singu-16: 10 (Ububanzi: Ukuphakama), futhi amaphikseli ahlelwe ngemivimbo ebheke phezulu. Ubukhulu bendawo yokubonisa ngu-216.96 × 135.6 (Ububanzi (Typ.). Ngokuya nge-baclighting, lo mkhiqizo usebenzisa umthombo wokukhanya wokukhanya okukhanyayo wempilo ngempilo yamahora angama-50k, kufaka phakathi umshayeli we-LED. I-EV101WXM-N81 isebenzisa ama-LVD (1 Ch, 8-bit) isikhombimsebenzisi esibonakalayo, ingqikithi yezikhonkwane ezingama-20, isebenzisa ukuxhumana okubulalayo, i-drive Screen Voltage ingu-3.3V (typ.). Isilinganiso sayo sokuvuselela esisemva vertical versical singama-60hz. Isebenza ku-20 ° C kuya ku-70 ° C nezitolo ku-30 ° C kuya ku-80 ° C. Ngokusekelwe kwi-backlight yayo yakwa-White Backle, impilo ingaphezulu kwamahora angama-50,000.
I-R-Star yaqhamuka eShenzhen, eChina, singumkhiqizi ochwepheshe wokugcina okuphezulu kakhulu, singanikeza kusuka kumamojula we-10.1 kuya ku-100 Ukugqamisa i-LCD, okugqamile kwe-Industry TFT-LCD, i-Transparent LCD ne-LCD ebonakalayo, i-LCD ephethwe kabili, i-LCD ephezulu-elihlangene ne-LCD ne-LCD ye-LCD ephezulu. Ngamafuphi, ukukhuphuka kube neminyaka engaphezu kwe-5 yokukhanya okuphezulu okuphezulu kwe-module module, iminyaka engu-8 ye-TFT module design, ucwaningo kanye nentuthuko, iminyaka engu-10 yekhwalithi ephezulu yokuhlinzekwa kwezinto ezibonakalayo.
| brand | BOE | Model name | EV101WXM-N81 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1280(RGB)×800, WXGA, 149PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.96×135.6(H×V)mm | Surface treatment | / |
| Visual size | 233.2×152.9×10.4(H×V×D) mm | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 233.2×152.9×10.4(H×V×D)mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Imodeli yobukhulu efanayo namapharamitha anjengokulandelayo
| brand | BOE | Model name | EV101WUM-N20 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1200, WUXGA, 224PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.806×135.504mm(H×V) | Surface treatment | / |
| Visual size | / | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 229.45×149.22(H×V)mm |
| Viewing Angle | 80/80/80/80(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 45 pins | ||
| work environment | Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C |
| brand | BOE | Model name | AT101WSM-N11-58P0 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×600, WSVGA, 117PPI | Pixel configuration | RGB vertical bar |
| Display Area | 222.72×125.28mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 226×128.6(H×V)mm | Contrast Ratio | 500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 235×144.9×5.44mm(H×V×D) |
| Viewing Angle | 80/80/60/70(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) , 60 pins , FPC | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
| brand | BOE | Model name | EV101WXM-N82 |
| size | 10.1 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1280(RGB)×800 [WXGA] 149PPI | Pixel configuration | RGB vertical bar |
| Display Area | 216.96 × 135.6 mm (H×V) | Surface treatment | / |
| Visual size | / | Contrast Ratio | 900:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 228.6 ×149.2×6 mm (H×V×D) |
| Viewing Angle | 85/85/85/85(Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 40 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
