Min. I-oda:1 Piece/Pieces
I-UV215FHM-N10 iyimodyuli engu-21.5-inch liquid crystal nge-A-SI TFT-LCD Technology, isixazululo esiboniswayo singu-1920 (RGB) × 1080 (FHD), isilinganiso se-Aspect singu-16: 9 (Ububanzi: Ukuphakama), kanye ne-pixel I-Adopts RGB ihlelwe ngemivimbo emile. Usayizi wendawo yokubonisa ngu-476.64 × 268.11 (W u-H h) mm, usayizi obonakalayo ngu-479.8 × 271.3 (w × 271.3 (w h h) mm, futhi usayizi wokubukeka ngu-495.2 (h) × 11.2 (d) mm.
Iphathwe njenge-matte (haze 25%), i-hard coating (3h), izinga lokushisa layo lingu-20 ° C, kanye nokushisa kwalo kwesitoreji kungu-30 ~ 85 ° C. Ngezimpawu zedijithali. Umthombo wokukhanya onqenqemeni, impilo yensizakalo yomthombo wokukhanya amahora angama-30k, usebenzisa ama-LVD (2 ch, 8-bit) izikhonkwane ezingama-30, i-drive voltage ingu-5.0V (nge-typ.) .
Q: Ngabe kukhona omunye usayizi noma ukucaciswa kungakhethwa?
A: Uma udinga osayizi noma imininingwane ehlukene, sizonikeza uhlelo olufanele kakhulu ngokuya ngezidingo zakho.
Q: Iyiphi insiza yakho yangaphambi kokuthengisa nangemva kokuthengisa kwensiza?
A: Ngokuya ngensizakalo yangaphambi kokuthengisa, sineqembu lokuthengisa eliqeqeshiwe neqembu lobuchwepheshe, abazimisele ukuphendula imibuzo yakho kungakapheli amahora angama-24.Ngoba insiza yokuthengisa ngemuva, singakwazi ukufundisa ukuthi ungayifaka kanjani, sebenzisa futhi ungene esikhundleni semojula eyonakele.
Q: Singabugcina kanjani ubudlelwano obuhle bebhizinisi lesikhathi eside?
A: Sigcina amanani amahle nezintengo zokuncintisana ukuqinisekisa ukuthi amakhasimende ayazuza; Sihlonipha wonke amakhasimende futhi sibaphathe njengabangane. Akunandaba ukuthi bavelaphi, sikwenza ngokweqiniso ibhizinisi nabo futhi senze abangane.
| brand | BOE | Model name | UV215FHM-N10 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -30 to 85 °C Operation Temperature: -20 to 80 °C |
Amapharamitha wemodeli yobukhulu efanayo
| brand | BOE | Model name | DV215FHM-R01 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Open zone | 479.8×271.3(H×V)mm | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -20 to 85 °C Operation Temperature: -20 to 85 °C |
