Min. I-oda:1 Piece/Pieces
I-Model No.: TDA150-005V01
I-TDA150-005v01 A-SI TFT-LCD 15-INCH Liquid Crystal Module, izici ezijwayelekile ziyi-LED LED Backlight, kufaka phakathi umshayeli we-LED, indawo ye-matte. Izinga lokushisa layo lokusebenza lingu-20 ~ 70 ° C, kanye nokushisa kwalo kwesitoreji kungu-30 ~ 80 ° C. Ukulungiswa kwesibonisi kungu-1600 (RGB) × 1200 (UXGA), futhi amaphikseli ahlelwe ngemivimbo eqondile ye-RGB. Usayizi wendawo yokubonisa ngu-304.8 × 228.6 (w × h) mm, futhi ubukhulu bangaphandle bungu-317.4 (W) × 242 (h) mm.
Kungumthombo wokukhanya onqenqemeni onqenqemeni lwempilo yamahora angama-30k, kufaka phakathi abashayeli be-LED. I-TDA150-005v01 i-admal LVD (2 CH, 8-bit) isikhombimsebenzisi esibonakalayo, ingqikithi yezikhonkwane ezingama-40, ezixhunywe yizikhungo, kanye ne-drive voltage ingu-3.3V (nge-typ.).
Q: Singobani?
A: I-R-Star yaqhamuka eShenzhen, eChina, singumkhiqizi ochwepheshe wokugcina okuphezulu okuphezulu, singanikeza kusuka kumamojula ayi-10,1 kuya kwayi-120 ukugqamisa amamojula we-10.1 Inkampani idlulise i-ISO9001 / iso14001 / CCC / CE / FCC / FCC / FCC / FCC / FCC / FCCS, inepulatifomu ephezulu ye-R & D, futhi isilinganiselo sezinkampani eziningi ezisezingeni lomhlaba.Nyakatho I-America, i-Afrika, Middle East, Europe, Central naseNingizimu Melika ne-Oceania.Sikholwe ukuthi uma usinika ithuba lokusebenza, sizoba ngumhlinzeki wakho othembekile eChina.
Q: Ngabe ungumkhiqizi (ifektri)?
A: Yebo, si. Futhi insizakalo ye-OEM / ODM etholakala lapha.Welfem ukuthola imibono yakho nathi. Kuyintokozo yethu ukuhlinzeka ngesisombululo esihle kakhulu kuwe.
Q: Singaqinisekisa kanjani ikhwalithi?
A: Njalo ukuhlolwa kokugcina ngaphambi kokuthumela.
| brand | BOE | Model name | TDA150-005V01 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Outline dimension | 317.4 × 242 mm (H×V) |
| Signal interface | LVDS (2 ch, 8-bit) ,erminal, 40 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
Ubukhulu obufanayo nemodeli yimi ngalendlela elandelayo:
| brand | BOE | Model name | RT150X0M-N10 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 1100cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Outline dimension | 326.5×253.5(H×V) |
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | DV150X0M-N16 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096(H×V) mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89(Min.)(CR≥10) | Outline dimension | 326.5×253.5×9.7mm(H×V×D) |
| Signal interface | 20 pins LVDS (1 ch, 8-bit) , erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | RV150U0M-N00 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8 × 228.6 mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | 307.2 × 231 mm (H×V) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 317.4×242 mm(H×V×D) |
| Viewing Angle | 85/85/85/85(Min.)(CR≥10) |
|
|
| Signal interface | LVDS (2 ch, 8-bit),40 pins, erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
Amathegi ashisayo: BOE TDA150-005v01 15 "Khombisa isikrini moudle, China, Factory, Isilinganiso, Isikrini Esibhekele i-LCD, isikrini esisezingeni eliphakeme se-LCD, i-2500 Screen Screen, gxila ama-IPS Isikrini esikude, isikrini esingu-15 4 TFT LCD , i-LCD Panel, imodyuli ye-LCD, isibonisi esiphakeme esiphakeme.
