I-Model No.: LA123WF1-SR03
Isinqumo sokubonisa isibonisi se-LA123WF1-SR03 ngu-1920 (RGB) × 720, isilinganiso se-Aspect singu-8: 3 (Ububanzi: Ukuphakama), futhi amaphikiseli ahlelwe emivishshi ye-RGB mpo. Ubukhulu bendawo yokubonisa ye-LA123WF1-SR03 ngu-292.032 × 109.512 (Ububanzi × 12 ukuphakama ngu-310 (ububanzi be-× (ubukhulu be-matte, ukuhlanganiswa kanzima.
[Imboni ephelele kunazo zonke yephaneli yezimboni yephaneli yezimboni]
I-Rising Star inikezela ngomugqa womkhiqizo ophelele kusuka ku-10.1 "kuya ku-100" ukuthola izicelo eziningi, ezihlotshiswe kakhulu, ukuqina okuqinile, ukuqina kwesimo sezulu esiphakeme, ukuqina kwesimo sezulu esiphakeme, nokuqina okude nokujikeleza okuphezulu kwezimboni zazo zonke izinhlobo zokubuyisa izindawo.
| brand | LG Display (LG Display) | Model name | LA123WF1-SR03 |
| size | 12.3 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution | 1920(RGB)×720 167PPI | Pixel configuration | RGB vertical bar |
| Display size | 292.032×109.512(H×V)mm | Surface treatment | Fog surface, Hard coating (3H) |
| Brightness(cd/m²) | 600 cd/m² (Min.) or customized | contrast | 800:1 (Min.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Appearance of size | 310×128×16.2mm(H×V×D) |
| Signal system | RSDS (2 Channel) , 110 pins , FPC |
|
|
| Maximum rated | Storage temperature: -40 ~ 95 °C Working temperature: -40 ~ 85 °C Vibration resistance: 3.0g (29.4m /s²) |
|
|
Amathegi ashisayo: 12.3inki LA1233WF1-SR03 LCD Panel, China, Factory, Iphaneli ye-LCD, 26 inch TFDOOR , I-1000nits Square LCD Display , i-LCD Panel, imodyuli ye-LCD, isibonisi esiphakeme kakhulu.
