I-Model No.: MG2350S01-1
Ukushisa okusebenzayo kwe-MG2350S01-1 yi-0 ~ 50 ° C, kanye nokushisa kwesitoreji kungu -20 ~ 60 ° C. Ilungele izimpawu zedijithali kanye nesikrini se-bar.
Ukulungiswa kwesibonisi kwe-MG2350S01-1 ngu-1920 (RGB) × 360, usayizi wendawo yokubonisa ngu-584.64 × 109.62 (Ububanzi) × 122.67 (Ububanzi) matte (haze 25%).
I-MG2350S01-1 yamukela ama-LVD (2 CH, 8-bit) isikhombimsebenzisi esibonakalayo, ingqikithi yezikhonkwane ezingama-30, ezixhunywe yizikhungo, kanye ne-drive voltage ingu-12.0v (typ.).
| brand | CSOT | Model name | MG2350S01-1 |
| size | 23.5inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×360 | Pixel configuration | RGB vertical bar |
| Display Area | 584.64×109.62(H×V)mm | Surface treatment | Fog surface(Haze 25%) |
| Visual size | / | Contrast Ratio | 4000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 596.42×122.67(H×V)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Backlight type | WLED,Including LED driver |
| Signal interface | 30 pins LVDS (2 ch, 8-bit)，erminal | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| supply voltage | 12.0V (Typ.) |
|
|
Amathegi ashisayo: 23.5 "CSOT MG2350S01-10s0150, China, ifektri, isikrini esishibhile, isikena se-LCD, isikrini se-Inch Outdoor LCD, isibonakaliso se-Inch Outdoor LCD, Isibonakaliso se-LCDOR , Amamojula we-LCD avulekile we-LCD , i-LCD Panel, imodyuli ye-LCD, isibonisi esiphakeme kakhulu.
