I-Model No.: LQ150X1LG96
Ukushisa okusebenzayo kwe-LQ150x1lg96 kungu-0 ~ 65 ° C, kanye nokushisa kwesitoreji kungu-30 ~ 70 ° C. Ilungele izinhlelo zezimboni, okuvelele kwangaphandle, imidlalo. Ukwelashwa okungaphezulu kwe-matte, ukuhlanganiswa kanzima (3h), kanye nesisindo seNet somkhiqizo kungu-950g (max.). Ngokuya nge-backlight, umthombo wokukhanya wohlobo oluseceleni unesifiso sokuphila kwamahora angama-30k.
Isixazululo se-LQ150x1lgg96 sibonisa ukuthi i-1024 (RGB) × 768 (XGA), isilinganiso se-Aspect singu-4: 3 (Ububanzi: Ukuphakama), futhi amaphikiseli ahlelwe emivishweni ebheke mpo. Usayizi wendawo yokubonisa ye-LQ150x1lg96 ngu-304.128 × 228.096 (w × 23 h) mm, futhi usayizi wangaphandle ngu-326.5 (h) × 12.1 (d) × 10.1 (d) mm.
| brand | Sharp | Model name | LQ150X1LG96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 1050cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1 mm(H×V×D) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) | work environment | Storage temperature: -30 to 70 °C Operation Temperature: 0 to 65 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
Amathegi ashisayo: I-15inch Sharp Lq150x1lg96 Iphaneli ye-TFT LVD, China, efektri, eshibhile, isikena, isikrini eshibhile, isikrini sangaphandle se-Insi I-Outdoor LCD Panel 2500 Nits , i-LCD Panel, imodyuli ye-LCD, isibonisi esiphakeme kakhulu.
