15.4 Inch Samsung Ltn154x9-L01

Min. I-oda:1 Piece/Pieces

Izimfanelo Zomkhiqizo
Ukupakisha nokulethwa
Other information

Izimfanelo Zomkhiqizo

I-Model No.: LTN154X9-L01

Ukupakisha nokulethwa

Ukuthengisa Amayunithi:

Piece/Pieces

Isingeniso Somkhiqizo

I-LTN154XX9-L01 Le module ifakwe i-CCFL Backlight, akukho mshayeli ongemuva, akunakuthinta. Izici zayo ezijwayelekile yilezi: umphambili wesibuko. Izinga lokushisa layo lokusebenza lingu-0 ~ 50 ° C, kanye nokushisa kwalo kwesitoreji kungu-20 ~ 60 ° C.

Isixazululo sokubonisa se-LTN154XX9-L01 (RGB) × 800 (WXGA), isilinganiso se-Aspect singu-16: 10 (Ububanzi: Ukuphakama), futhi amaphikiseli ahlelwe ngemivimbo ebheke phezulu. Ubukhulu bendawo yokubonisa ngu-331.2 × 207 (Ububanzi × (usayizi obonakalayo ngu-335.0 × 210.7 (ububanzi × (ububanzi) Iphathwe i-Mirror Surface (Haze 0%), i-hard coating (3h).

10.1 inch panel

Q: Iyiphi insiza yakho yangaphambi kokuthengisa nangemva kokuthengisa kwensiza?

A: Ngokuya ngensizakalo yangaphambi kokuthengisa, sineqembu lokuthengisa eliqeqeshiwe neqembu lobuchwepheshe, abazimisele ukuphendula imibuzo yakho kungakapheli amahora angama-24.Ngoba insiza yokuthengisa ngemuva, singakwazi ukufundisa ukuthi ungayifaka kanjani, sebenzisa futhi ungene esikhundleni semojula eyonakele.

Q: Ngingawuthola kanjani umkhiqizo ofanele?

A: Sicela usithumele izidingo zakho, sizoncoma imikhiqizo yethu ejwayelekile, uma kungalungile, sizokwenza ukulungiswa okudingekayo nokuzifiso.

Ukukhanya okuphezulu kwe-LCD

brand	SAMSUNG	Model name	LTN154X9-L01
size	15.4 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800	Pixel configuration	RGB vertical bar
Display Area	331.2×207(H×V)mm	Surface treatment	Glare (Haze 0%), Hard coating (3H)
Visual size	335.0×210.7(H×V)mm	Contrast Ratio	600:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	344×226×7(H×V×D)mm
Viewing Angle	65/65/50/50 (Typ.)(CR≥10)	work environment	Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C
Signal interface	LVDS (1 ch, 6-bit) ,erminal,30pins
supply voltage	12.0V (Typ.)

Amathegi ashisayo: 15.4 inch Samsung Ltn154x9-L01, China, efektri, Isilinganiso, Isikrini esiseduze, isikrini se-LCD, isikrini sokukhanya kwe-Ultra, isikrini sokukhanya kwe-Ultra, isikrini sokukhanya kwe-ultra I-LCD , i-LCD Panel, i-LCD module, isibonisi esiphakeme kakhulu.
