Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Min. I-oda:1 Piece/Pieces
Ibhulogi: Ringlcd
Ukukhiqiza: 150KK
Indawo Yomsuka: UShen Zhen
Isitifiketi: CE/ROSH/UL/ISO9001
| Panel Brand | BOE | Panel Model | MT220WPM-N10 |
| Panel Size | 22.0" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1680(RGB)×1050, WSXGA+, 90PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 473.76(W)×296.1(H) mm | Bezel Opening | 477.7(W)×300.1(H) mm |
| Outline Size | 493.7(W)×320.1(H) ×10.7(D) mm | Surface | Antiglare (Haze 25%), Hard coating(3H) |
| Brightness | 1000nit or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive |
| Display Colors | 16.7M 72% NTSC | Response Time | 1.5/3.5 (Typ.)(Tr/Td) |
| Frequency | 60Hz | Lamp Type | 3 strings WLED , 40K hours , Without Driver |
| Weight | 1.83Kgs (Typ.) | Touch Screen | Without |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
| Input Voltage | 5.0V (Typ.) | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C | ||
Iphaneli ye-LCD ye-Ultra-Fighter, ukugqama kufinyelela ku-1000nit, isithombe sisacacile ekukhanyisweni okuqondile, isixazululo esifanelekile sangaphandle newindi elibheke phambili, le module ye-LCD yelanga ingahle ibe nokukhanya okwenziwe ngokwezifiso: 600-1000nit.
Isikrini se-LCD yedijithali esingu-21.5
1, Isakhiwo se-Backlight Module : Zonke Izinhlaka ze-Aluminium, ukukhanya nokuncane, ukubukeka okuhle, ukudicilela okusebenzayo kokushisa.
2, I-LED Backlight : Ubuhlalu obumhlophe baholela ubuhlalu, ukukhanya okuphezulu, i-50k HRS LifeSpan, ukufana okukhanyayo okuphelele.
3, Hlanganisa umucu okhanyayo : Isakhiwo se-Aluminium + sikhanyise emuva emuva, lungisa i-LED backlight kwisakhiwo se-aluminium ukwenza lula ukufudumeza.
I-4, Isibani se-Article : Isakhiwo se-Aluminium + esikhawini se-LED, lungisa i-LED Backlight kwi-aluminium
21.5 inch light LCD module lunlight sunlight i-LCD Panel
I-Ultra slim 21.5 Inch LCD module Xhuma izintambo bese unamathisela ifilimu ekhombisa i-3M ukwenza isightlight sibonise umfaniswano ovulekile kwiseli yokuqala evulekile yomkhiqizo. Faka igumbi elihlanzekile le-10,000 bese uhlola umthombo wokukhanya ukuze uqinisekise ukuthi i-LED Backlight isebenza ngokujwayelekile.
I-Ultra Slim 21.5 Inch LCD module enama-Place Optical Flims
I-Slim High Brightness LCD module ibeka ama-Flims we-Optical Flims: Iplanethi ye-Disecsion, ifilimu lokuphazamiseka, ifilimu lokuthuthukisa isicwebezeli, njll ukuthuthukisa ukukhanya kwesibani.
Slim high hightness Hrightness LCD module nge-LG / Samsung / Auo / Boe, njll.
Le slim 21.5 Inch LCD module ehlanganisa lg / Samsung / Auo / Boe, njll.
I-Ultra slim 21.5 Inch LCD module nge-T-Con Board
I-21.5 inch light LCD module acleibles T-Con Board, amabhodi okushayela aholwa, ukunikezwa kwamandla kwe-DC12V njalo.
I-21.5 inch ephezulu yemodyuli ephakeme ngokuhlolwa kokukhanya
Lokhu kukhanya okuphezulu okuphezulu okungu-21.5 inch LCD module, kudlulile ukuhlolwa kokukhanya, ukuhlolwa kokukhanya kombala okugqamile, umhloli we-topCon Bm-7 umbala wokukhanya.
Amathegi ashisayo , isikrini sedijithali amasentimitha angama-55
10.1 Inch 1200nit Outdoor touch LCD PANEL
MT220WPM-N10 22.0 "1000nit lcd TV Panel
