Min. I-oda:1 Piece/Pieces
I-Model No.: MG4700S01-1
Ibhulogi: Ringlcd
Ukukhiqiza: 220k
Indawo Yomsuka: Izitsha zokudlela zebumba uqobo
Isitifiketi: CD/ROSH/ISO9001
I-MG4700S01-1 inesinqumo sokubonisa esingu-3840 (RGB) × 180, isilinganiso se-Aspect of> 3: 1 (Ububanzi: Ukuphakama), futhi amaphikseli ahlelwe emivishweni ebheke phezulu ye-RGB. Ubukhulu bendawo yokubonisa ngu-1192.3 × 55.89 (w × 55.89 (W × 55.89 (W usayizi wangaphandle ngu-1208.12 × 72.59 (w × × h) mm. Ukushisa okusebenzayo kwe-MG4700S01-1 yi-0 ~ 50 ° C, kanye nokushisa kwesitoreji kungu -20 ~ 60 ° C.
[Inkonzo yokumisa eyodwa, ukusebenza komhlaba wonke kanye nokuxhaswa kwasendaweni]
I-Rising Star inikezela ngamakhasimende insiza yezitolo eyodwa, futhi imikhiqizo idlulise ukuhlolwa kanzima ukuze iqinisekise ukuthi ikhwalithi ihlangabezana nezincazelo; Futhi usungule uhlelo lokulawulwa kwekhwalithi oluningi ngokwezinga ngokuya ngamazinga wekhwalithi yamazwe omhlaba. Ukusebenza komhlaba wonke, ukuhlinzeka ngokubonisana kwezobuchwepheshe okuphelele, ukusekelwa komkhiqizo kanye nezinsizakalo zebhizinisi.
| brand | CSOT | Model name | MG4700S01-1 |
| size | 47inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 3840(RGB)×180 81PPI | Pixel configuration | RGB vertical bar |
| Display Area | 1192.3×55.89(H×V)mm | Surface treatment | Fog surface(Haze 25%) |
| Visual size | / | Contrast Ratio | 3000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 1208.12×72.59 (H×V)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| Signal interface | V-by-One 8 lane,51 pins,erminal | ||
| supply voltage | 12.0V (Typ.) |
Amathegi ashisayo: csot mg4700s01-1 lcd moldle, China, Factory, eshibhile, inani lentengo, isikrini se-LCD esibheke e-LCD, isikrini sangaphandle se-LCD, i-LCD ephansi yokusebenzisa i-LCD, Outdoor LCD 06 intshi, i-55 inch Outdoor TV
