Module we-mnf601-1 lcd module

Min. I-oda:1 Piece/Pieces

Izimfanelo Zomkhiqizo
Ukupakisha nokulethwa
Other information

Izimfanelo Zomkhiqizo

I-Model No.: MNF601EA1-1

Ukupakisha nokulethwa

Ukuthengisa Amayunithi:

Piece/Pieces

Isingeniso Somkhiqizo

Ukushisa okusebenzayo kwe-MNF601-1 ngu-0 ~ 50 ° C, kanye nokushisa kwesitoreji kungu -20 ~ 60 ° C. Ukulungiswa kwesibonisi kwe-MNF601-1 ngu-3840 (RGB) × 2160 (UHD), isilinganiso se-Aspect singu-16: 9 (Ububanzi: Ukuphakama), futhi amaphikiseli ahlelwe emivishshi ye-RGB mpo. Usayizi wendawo yokubonisa ye-MNF601-1 ngu-345.6 × 194.4 (Ububanzi × (usayizi ongu-350.72 (ububanzi) × 216.07 (Ububanzi) × 2.6

lcd display

Ukuma okwenziwe ngokwezifiso ukuze uhlangabezane nezidingo ezahlukahlukene zezemvelo.

Amaphaneli okubonisa izincazelo ezikhuphukayo afaka isici esiphakeme se-Ultra-High, ukubonakala kwangaphandle, kanye nempilo yomkhiqizo omude. Izicelo zomkhiqizo zimboza imishini ye-othomathikhi ye-othomathikhi (i-ATM), iphuzu le-terminal lemishini yokuthengisa (i-POS), ulwazi olusebenzayo lwe-Kiosks (i-Induclial), ukubonwa kwezohwebo, imishini yezokwelapha, ezenzakalelayo zezokwelapha, ukuzijabulisa efektri, ukuzijabulisa kwendiza kanye Imibukiso yasolwandle ilindile. high brightness LCD

brand	CSOT	Model name	MNF601EA1-1(CSO1500)
size	15.6inch	Screen type	LTPS TFT-LCD,LCD module
resolution ratio	3840(RGB)×2160, UHD	Pixel configuration	RGB vertical bar
Display Area	345.6×194.4(H×V)mm	Surface treatment	mirror(Haze 0%)，Hard coating (3H)
Visual size	/	Contrast Ratio	1500:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	350.72×216.07×2.6(HVD)mm
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	work environment	Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C
Signal interface	eDP (4 Lanes),eDP1.4,HBR2 (5.4G/lane),40 pins,erminal
supply voltage	3.3V (Typ.)
