Ibhulogi: Ringlcd
Ukukhiqiza: 210k
Indawo Yomsuka: Izitsha zokudlela zebumba uqobo
Isitifiketi: CE/ROSH/ISO9001
I-module screen screen, ifakwe i-wacklight ye-wackled, kufaka phakathi i-LED Driver backlight drive, akunakuthinta. Ukushisa okusebenzayo kwalesi siboniso kungu-0 ~ 50 ° C, kanye nokushisa kwesitoreji kungu -20 ~ 65 ° C. Ilungele imikhiqizo efana nezimpawu zedijithali.
Isixazululo sokubonisa i-LTI480HN02 singu-1920 (RGB) × 1080 (FHD), isilinganiso se-Aspect singu-16: 9 (Ububanzi: Ukuphakama), futhi amaphikiseli ahlelwe emivishweni ebheke mpo. Usayizi wendawo yokubonisa yesikrini sokubonisa ngu-1054.08 (W) × 592.92 (h) mm, usayizi wokubukeka ngu-1079.88 (h) × 2218.88 (h) × 2218.88 (h) × 2218.82 (h) × 22,9 (d) mm, nosayizi obonakalayo ngu-1060.08 (W) × I-598.92 (h) mm, ukwelashwa okungaphezulu yi-matte (haze 25%), i-hard coating (2h), nomthombo wokukhanya okukhanyayo okukhanyayo (phansi).
Q: Ingabe ungumkhiqizi (ifektri)?
A: Yebo, si. Futhi insizakalo ye-OEM / ODM etholakala lapha.Welfem ukuthola imibono yakho nathi. Kuyintokozo yethu ukuhlinzeka ngesisombululo esihle kakhulu kuwe.
Q: Singaqinisekisa kanjani ikhwalithi?
A: Ukuhlolwa kokugcina njalo ngaphambi kokuthunyelwa;
| brand | SAMSUNG | Model name | LTI480HN02 |
| size | 48 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 | Pixel configuration | RGB vertical bar |
| Display Area | 1054.08×592.92(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (2H) |
| Visual size | 1060.08×598.92(H×V)mm | Contrast Ratio | 4000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 1079.88×618.72×22.9(H×V×D)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 65 °C Operation Temperature: 0 to 50 °C |
| Signal interface | LVDS (2 ch, 8-bit) ,erminal,51pins |
|
|
| supply voltage | 12.0V (Typ.) |
|
|
Amathegi ashisayo: Samsung 48inch LTI480HN02 Shoverview, China, Factoral, eshibhile, isilinganiso, i-Intshi ye-Uk, isikrini sangaphandle se-LCD, isikrini sokukhangisa sangaphandle, isikrini sokubonisa sokukhangisa , Iphaneli ye-LCD, imodyuli ye-LCD, isibonisi esiphakeme kakhulu.
